• Chrome front bumper
• Chrome grille/headlamp surround
• Bed-rail/tailgate moldings
• High-mounted stop light w/cargo box light
• Dual manual aero mirrors w/black caps
• Flush window glass
• Interval wipers
• Black door handles
• Removable locking tailgate w/black handle

• Split-back cloth bench seat
• Color-keyed vinyl floor covering
• Wraparound ergonomic instrument panel w/illuminated controls
• Voltmeter, oil pressure/temp/speed/fuel gauges
• Electronic AM/FM stereo radio w/4 speakers, digital clock
• Dual instrument-panel-mounted cupholders
• Auxiliary pwr point
• Vinyl upper door trim w/integral armrest, map pocket
• Headliner
• Cloth sun visors w/LH strap, RH mirror
• Dome light w/dual map lights
• Underhood light
• Back panel cover

• Driver & front passenger air bags
• Seat belts w/adjustable shoulder
• Rear-wheel anti-lock brake system
• Side door intrusion beams

4.2L EFI V6 ENGINE

• (STD)

• 4 Speakers
• ABS brakes
• AM/FM radio
• Bumpers: chrome
• Driver door bin
• Dual front impact airbags
• Front anti-roll bar
• Front reading lights
• Front wheel independent suspension
• Passenger cancellable airbag
• Passenger vanity mirror
• Poly Knit Bench Seat
• Power steering
• Variably intermittent wipers
• Voltmeter

• Mileage
• EPA Fuel Economy Est - City (MPG): 17
• EPA Fuel Economy Est - Hwy (MPG): 22
• Electrical
• Cold Cranking Amps @ 0° F (Primary): 540
• Maximum Alternator Capacity (amps): 95
• Maximum Alternator Watts: 1425
• Cooling System
• Total Cooling System Capacity (qts): 15.7
• Weight Information
• Gross Axle Wt Rating - Front (lbs): 2500
• Gross Axle Wt Rating - Rear (lbs): 2900
• Curb Weight - Front (lbs): 2236
• Curb Weight - Rear (lbs): 1614
• Gross Vehicle Weight Rating Cap (lbs): 5550
• Gross Combined Wt Rating (lbs): 6,500
• Trailering
• Dead Weight Hitch - Max Trailer Wt. (lbs): 2,000
• Dead Weight Hitch - Max Tongue Wt. (lbs): 200
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 2,000
• Wt Distributing Hitch - Max Tongue Wt. (lbs): 300
• Fifth Wheel Hitch - Max Trailer Wt. (lbs): 2,000
• Fifth Wheel Hitch - Max Tongue Wt. (lbs): 500
• Suspension
• Suspension Type - Front: Coil Spring
• Suspension Type - Rear: 2-Stage Multi-Leaf
• Spring Capacity - Front (lbs): 2500
• Spring Capacity - Rear (lbs): 2900
• Axle Type - Front: Twin Forged SLA
• Axle Type - Rear: Semi-Floating
• Axle Capacity - Front (lbs): 3400
• Axle Capacity - Rear (lbs): 3800
• Axle Ratio (:1) - Rear: 3.08
• Shock Absorber Diameter - Front (mm): 30.2
• Shock Absorber Diameter - Rear (mm): 30.2
• Stabilizer Bar Diameter - Front (in): 1.18
• Brakes
• Brake Type: Power
• Brake ABS System: Rear Wheel
• Disc - Front (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 12.13 x - TBD -
• Drum - Rear (Yes or ): Yes
• Rear Drum Diam x Width (in): 11.03 x 2.25
• Tires
• Front Tire Order Code: T52
• Rear Tire Order Code: T52
• Spare Tire Order Code: T52
• Front Tire Size: P235/70R16SL
• Rear Tire Size: P235/70R16SL
• Spare Tire Size: P235/70R16SL
• Front Tire Capacity (lbs): 1804
• Rear Tire Capacity (lbs): 1804
• Spare Tire Capacity (lbs): 1804
• Revolutions/Mile @ 45 mph - Front: 719
• Revolutions/Mile @ 45 mph - Rear: 719
• Revolutions/Mile @ 45 mph - Spare: 719
• Wheels
• Front Wheel Size (in): 16.0 x 7.0
• Rear Wheel Size (in): 16.0 x 7.0
• Spare Wheel Size (in): 16.0 x 7.0
• Front Wheel Material: Steel
• Rear Wheel Material: Steel
• Spare Wheel Material: Steel
• Steering
• Steering Type: Power
• Steering Ratio (:1), On Center: 14
• Turning Diameter - Curb to Curb (ft): 40.49
• Turning Diameter - Wall to Wall (ft): 42.22
• Frame
• Frame Type: Ladder
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 25.0
• Fuel Tank Location: Midship
• Exterior Dimensions
• Wheelbase (in): 119.9
• Length, Overall w/o rear bumper (in): 202.2
• Width, Max w/o mirrors (in): 78.4
• Height, Overall (in): 72.7
• Overhang, Front (in): 37.2
• Overhang, Rear w/o bumper (in): - TBD -
• Front Bumper to Back of Cab (in): - TBD -
• Cab to Axle (in): - TBD -
• Cab to End of Frame (in): - TBD -
• Ground to Top of Load Floor (in): 32.5
• Ground to Top of Frame (in): - TBD -
• Frame Width, Rear (in): - TBD -
• Ground Clearance, Front (in): - TBD -
• Ground Clearance, Rear (in): - TBD -
• Cargo Area Dimensions
• Cargo Box Length @ Floor (in): 78.8
• Cargo Box Width @ Top, Rear (in): 62.1 @ Belt
• Cargo Box Width @ Floor (in): 60.3
• Cargo Box Width @ Wheelhousings (in): 50.0
• Cargo Box (Area) Height (in): 19.7
• Tailgate Width (in): - TBD -
• Cargo Volume (ft³): 58.6
• Interior Dimensions
• Passenger Capacity: 3
• Front Head Room (in): 40.8
• Front Leg Room (in): 40.9
• Front Shoulder Room (in): 63.8
• Front Hip Room (in): 61.3
• Summary
• Vehicle Name: Ford F-150
• Body Style: Reg Cab 6.5' Styleside
• Body Code: 119.9" WB
